A brighter diagnosis
Coronis Fusion, Barco's renowned multi-modality display for radiologists, now comes in a new, energy-efficient and lightweight design. Bright on so many levels, Coronis Fusion has been designed to help radiologists provide care with confidence.
See more details quickly thanks to the high brightness, high contrast ratio and best-in-class image quality. What's more, the wide color gamut in combination with SteadyColor™ calibration technology helps you see even more colors and more details on the 30-inch screen.
Smart workflow
Designed for your comfort and to boost productivity, Coronis Fusion comes with smart image-enhancing features and workflow tools. The display's wide viewing angle combined with the SoftGlow™ task and wall light help reduce eye strain. Thanks to SpotView, radiologists can further improve detection accuracy as well as reading productivity.
Effortless quality & compliance
Like all of Barco's medical display systems, Coronis Fusion comes with QAWeb Enterprise, a cloud-based technology for automated calibration, Quality Assurance and compliance to ensure maximum uptime of the display with no need for human intervention.
A one-stop-shop solution
Barco medical display systems include exclusive display controllers that are validated with the latest workstations and with all major PACS applications. All components are under the full 5-year warranty (including the display backlight) for complete peace of mind.
Ensuring diagnostic confidence with MDR Class IIa
Our radiology displays are MDR-certified as Class IIa. Their product information has been reviewed and cleared by independent medical and technical experts, and is audited yearly. In other words, we ensure diagnostic confidence and peace of mind for our users.
- General Information
- Manufacturer
- Barco
- Manufacturer Website Address
- http://www.barco.com
- Brand Name
- Barco
- Product Line
- Coronis Fusion
- Product Type
- LED Monitor
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Number of Screens
- 1
- Screen Size Class
- 30"
- Viewable Screen Size
- 30.4"
- Screen Mode
- WQSXGA
- Panel Technology
- In-plane Switching (IPS) Technology
- Response Time
- 18 ms
- Response Time Details
- 18ms (Tr+Tf)/2
- Aspect Ratio
- 16:10
- Pixel Pitch
- 0.19950 mm x 0.19950 mm
- Horizontal Viewing Angle
- 178°
- Vertical Viewing Angle
- 178°
- Backlight Technology
- LED
- Features
- Digital Uniformity Correction
- SteadyColor Calibration Technology
- Ambient Light Sensor
- I-Guard
- Integrated Front Sensor (IFS)
- Anti-reflective
- Protective Glass
- Wide Viewing Angle
- Picture Archiving and Communication System (PACS)
- Ambient Light Compensation (ALC)
- Adjustable Stand
- Yes
- Stand Adjustments
- Swivel
- Height
- Tilt
- Active Display Area (H x V)
- 25.75" x 16.10"
- Video
- Maximum Resolution
- 3280 x 2048
- Contrast Ratio
- 2,000:1
- Brightness
- 1050 Nit
- Interfaces/Ports
- USB
- Yes
- DisplayPort
- Yes
- Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 4
- Number of USB 2.0 Upstream Ports
- 1
- Number of USB 2.0 Downstream Ports
- 3
- Number of DisplayPorts
- 3
- Built-in Devices
- Built-in Devices
- USB Hub
- Environmental Conditions
- Operating Temperature Range
- 32°F (0°C) to 95°F (35°C)
- Operating Humidity Range
- 20% to 85% (Non-condensing)
- Power Description
- Frequency
- 50 Hz
- 60 Hz
- Maximum Power Consumption
- 80 W
- Physical Characteristics
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 100 x 100
- Color Family
- Dual Color
- Color
- Black
- White
- Height
- 18.8"
- Width
- 28.1"
- Depth
- 2.9"
- Height with Stand
- 24.57"
- Width with Stand
- 28.11"
- Depth with Stand
- 9.45"
- Compressed Height with Stand
- 20.63"
- Extended Height with Stand
- 24.57"
- Weight (Approximate)
- 28.88 lb
- Weight with Stand (Approximate)
- 39.02 lb
- Miscellaneous
- Package Contents
- Coronis Fusion MDCC-6530 Widescreen LED Monitor
- User Guide
- Documentation Disc
- System Sheet
- Video Cables
- Mains Cables
- USB Cable
- Application/Usage
- Hospital
- Environmental Compliance
- Eurasian Economic Union Restriction of Hazardous Substances (EAEU RoHS)
- China Restriction of Hazardous Substances (China RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
